• Shot Timer: Precise and reliable coffee dispensing timing for consistent results.
• Ring Group: Chromed brass group ring, electronically controlled to maintain the ideal extraction temperature.
• Digitally Programmable Group Temperature: Set group temperature from 90°C to 98°C using the push-button panel for exact control.
• LED Work Surface Lighting: Allows effective work in any lighting condition (optional).
• Fast Maintenance: Simplified access to internal parts for easy servicing.
• Programmable Steel Boiler and Temperature Control: Set your AISI 316L boiler to 1.0/1.2/1.4 bar, digitally controlled.

Key Features:

• Dual-Reading Pressure Gauge: Simultaneous control of line pressure, boiler pressure, and coffee brewing pressure for optimal performance.
• Electronic Autolevel: Automatically fills the boiler and maintains the correct level through an electronic level probe.
• Static Boiler Temperature Relay: Allows for precise temperature adjustments.
• Automatic Cleaning Cycle: Programmable group cleaning process with multiple washing cycles.
• Group Flushing: Clean your group with a simple push of a button, ensuring cleanliness at all times.
• High-Performance Volumetric Pump: Delivers constant pressure, even during prolonged and simultaneous use of multiple functions.

Optional Features:

• Competition Filters: Designed to enhance the aromas and fragrances of coffee, with an exclusive Sanremo design.
• Cup Heating Plate: Programmable heating element to maintain cups at the ideal temperature.
• Cash Account System: RS-232 communication for credit management devices, allowing controlled dispensing.
• Enhanced Heating Element: Improves the heating efficiency.
• IoT Connectivity: App and cloud connection for remote machine control and monitoring.
• External Volumetric Pump: For advanced control.
• Aesthetic Side Panels: Available in various finishes to suit your style.
• Naked Filter Holders: Optional filter holders for a unique brewing experience.

• Width: 808 mm
• Depth: 555 mm
• Height: 500 mm
• Voltage: 240V
• Cup Heating Plate Dimensions: 1947 cm²
• Steam Boiler Capacity: 7 liters
• Net Weight: 61.5 kg
• Gross Weight: 85 kg
• Max Input Boiler/Steam Boiler Power: 4.2 kW / 3.5 kW, 5.4 kW / 4.5 kW
• Cup Heating Plate Power (Optional): 0.2 kW / 0.25 kW
• Pump Power: 0.25 kW

Technical Features

• 2 Steam Taps
• 1 Water Tap
• 1 Filter Holder for Single Cup
• 3 Filter Holders for Two Cups

Daily Cleaning

Wipe and purge the steam wand after each use to prevent milk buildup, rinse portafilters and filter baskets, clean the drip tray, and backflush the group head to remove coffee oils and residue.

Weekly Maintenance

Soak portafilters, baskets, and shower screens in an approved cleaning solution, inspect group head gaskets and screens, and perform a deeper backflush to keep internal components clean.

Long-Term Care

Maintain proper water filtration to prevent scale buildup and descale the machine as needed based on water quality and usage to ensure long-lasting performance and consistent espresso quality.

For this single-boiler espresso machine, we recommend using a BWT Single Cartridge Water Filter or a comparable inline filtration system designed to reduce hardness, chlorine, and sediment. Regular filter replacement based on water usage and local water quality is strongly advised to extend the life of the machine and preserve flavor clarity.

Voltage: 220-240 VAC
Wattage: 3300W
Electrical: Requires a 230V circuit (dedicated circuit strongly recommended)

Summary:
This machine runs on a 230V power supply, making it ideal for commercial cafés, high-volume service, and serious espresso setups where stronger electrical capacity is available. With a compatible-watt draw, it should be connected to a dedicated circuit to ensure stable performance—especially if you’re running other equipment nearby (grinder, fridge, hot water tower). This setup is best for fixed locations with proper electrical infrastructure, rather than most mobile coffee carts where 230V isn’t always available.
